Energy Saving Gyratory Crusher Max Feeding Size 1100mm-1500mm With AC Motor

Ask Lasest Price
Brand Name :	SANME
Model Number :	SMX810,SMX830,SMX1040,SMX1050,SMX1150,SMX1450
Certification :	ISO&CE
Price :	Negotiate
Payment Terms :	T/T, L/C
Supply Ability :	50 sets per Month
Delivery Time :	2 months

Add to Cart

Product Details
Company Profile

Energy Saving Gyratory Crusher Max Feeding Size 1100mm-1500mm With AC Motor

Energy Saving Gyratory Crusher Max Feeding Size 1100mm-1500mm With AC Motor

Performance Features of Hydraulic Cone Crusher

1. High crushing ratio & production efficiency.
2. Low energy consumption and running cost.
3. Excellent granule of finished products.
4. High automatic discharging and high degree of automation .
5. Thin oil lubrication system improves the working life.
6. Reliable and advanced.
7. Flexible application and easy maintenance.

Advantage:

1. Optimized cavity, higher capacity

2. The mantle of the same diameter, the crushing stroke longer, larger crushing ratio, high output, low energy consumption;The effect of

3. laminated crushing under full load makes particle-size distribution more steady, shape of product (cubic) more excellent.

Product Description

1. Energy-Saving about 20%~35%.
2. Competitive Price
3. Stable performance
4. ISO 9001.,CE

SMH Series Standard Head Hydraulic Cone Crushers:

Model	Max Feeding Size(mm)	Discharge Range(mm)	Moter Power(kw)	Capacity(t/h) -- open circuit,closed discharge(mm)
Model	Max Feeding Size(mm)	Discharge Range(mm)	Moter Power(kw)	9	13	16	19	22	26	32	38	51	63	76	89
SMH120C	160	22~32	75-90					120	130	150
SMH120M	130	13~26	75-90		70	85	100	120	130
SMH120F	102	9~22	75-90	58	70	85	90	110
SMH180C	180	22~32	132-160					185	195	215
SMH180M	140	13~32	132-160		90	115	135	160	180	200
SMH180F	60	9~22	132-160	60	80	100	120	140
SMH250EC	260	26~51	160-200						250	290	340	395
SMH250C	220	19~51	160-200				182	209	236	279	334	365
SMH250M	150	16~38	160-200			140	165	185	220	275	330
SMH250F	115	13~31	160-200		115	133	156	176	192	226
SMH350EC	315	38~63	250-280								555	649	766
SMH350C	230	26~63	250-280						366	430	468	629	657
SMH350M	205	22~52	250-280					296	343	387	427	479
SMH350F	180	16~38	250-280			212	239	270	320	355	374
SMH550EC	450	38~89	355-400								920	1179	1380	1475	1566
SMH550C	350	31~76	355-400							800	850	1100	1288	1398
SMH550M	320	25~63	355-400						612	735	815	980	1137
SMH550F	268	19~52	355-400				392	453	535	620	725	867

Technical Date of SMH Series Short Head Hydraulic Cone Crushers:

Model	Max Feeding Size(mm)	Discharge Range(mm)	Moter Power(kw)	Capacity(t/h) -- open circuit,closed discharge(mm)
Model	Max Feeding Size(mm)	Discharge Range(mm)	Moter Power(kw)	3	5	6	9	13	16	19	22	26	32	38
SMH 120DC	70	6-19	75-90			62	82	102	123	138
SMH 120DM	51	5-16	75-90		45	58	78	99	116
SMH 120DF	35	3-13	75-90	30	45	58	78	95
SMH 180DC	70	6-9	75-90			72	90	108	131	158
SMH 180DM	51	5-16	75-90		68	76	95	118	145
SMH 180DF	35	3-13	75-90		70	82	95	120
SMH 250DC	89	9-22	160-220				126	168	196	215	252
SMH 250DM	70	6-16	160-220			88	117	156	172
SMH 250DF	54	5-16	160-220		63	86	115	143	169
SMH 350DEC	133	13-25	250-280					262	308	322	358	385
SMH 350DC	133	10-25	250-280				208	262	308	322	358	385
SMH 350DM	89	6-19	250-280			136	186	233	260	293
SMH 350DF	70	6-13	250-280			136	186	233
SMH 550DEC	203	16-25	400						516	593	656	696
SMH 550DC	178	13-25	400					455	498	552	600	643
SMH 550DM	133	10-19	400				355	416	472	530
SMH 550DF	105	6-16	400			276	355	385	448

SMX series gyratory crusher.pdf
